nput Voltage: AC 110/220 V
Input Voltage Range: AC 100, 127 / 200, 240 V
Frequency Required: 47, 63 Hz
Output Voltage: +3.3, +5, ±12 V
Power Output Connectors Details:
1x power 24 pin main output ,
2 x power 8 pin +12V ,
15 pin Serial ATA power,
4 pin internal power
Power Capacity: 550 Watt
Output Current: +3.3V, 18 A / 0.5 A , +5V, 15 A / 0.3 A , +12V1, 24 A / 0.7 A , -12V, 0.5 A / 0 A , +5VSB, 3 A / 0 A , +12V2, 24 A / 0.7 A , +12V3, 24 A / 1.5 A
Efficiency: 85%
80 PLUS Certication: 80 PLUS Silver
Features: Overheat protection, overcurrent protection, overvoltage protection
Environmental Parameters
Min Operating Temperature: 32 °F
Max Operating Temperature: 122 °F
Compatibility Information
Designed For: Intel Server System P4208CP4MHGC, P4308CP4MHEN, P4308CP4MHGC
